| BUCK PRESS |
|
| Air operated presses are very user-friendly and versatile. They feature an increased thrust power and offer the possibility to regulate the pressing pressure as needed, as well as to apply differently shaped ironing boards. |
|
| Model |
BP |
| Compressed air supply(bar) |
6 |
| Air working pressure (bar) |
7 |
| Air consumption ni /min |
45 |
| Steam pressure ( bar ) |
4 |
| Steam consumption kg/ hr |
12 |
| Overall dimensions (mm) |
1100x1070x1500 |
| Net Weight (kg) |
204 |
| Vacuum –unit motor (hp) |
0.5 |
| Boiler heater ( kw) |
8 |
| Pump motor(hp) |
0.75 |
| Compressor motor (hp) |
2 |
| Over all Dimensions including boiler & compressor (mm) |
1370x1070x1500 |
| Net Weight (kg) |
284 |
|
|
|
 |
|
|
|
| COLLAR AND CUFF PRESS |
|
| Air operated presses are very user-friendly and versatile. They feature an increased thrust power and offer the possibility to regulate the pressing pressure as needed, as well as to apply differently shaped ironing boards. |
|
| Model |
cc |
| Compressed air supply(bar) |
6 |
| Air working pressure (bar) |
7 |
| Air consumption ni /min |
45 |
| Steam pressure ( bar ) |
5 |
| Steam consumption kg/ hr |
14 |
| Overall dimensions (mm) |
1100x1070x1500 |
| Net Weight (kg) |
250 |
| Vacuum –unit motor (hp) |
0.5 |
| Boiler heater ( kw) |
8 |
| Pump motor(hp) |
0.75 |
| Compressor motor (hp) |
2 |
| Over all Dimensions including boiler & compressor (mm) |
1370x1070x1500 |
| Net Weight (kg) |
330 |
|
|
|
 |
|
|
|
| PANT PRESS |
|
| Air operated presses are very user-friendly and versatile. They feature an increased thrust power and offer the possibility to regulate the pressing pressure as needed, as well as to apply differently shaped ironing boards. |
|
| Model |
pp |
| Compressed air supply(bar) |
6 |
| Air working pressure (bar) |
7 |
| Air consumption ni /min |
45 |
| Steam pressure ( bar ) |
5 |
| Steam consumption kg/ hr |
25 |
| Overall dimensions (mm) |
1620x1070x1500 |
| Net Weight (kg) |
285 |
| Vacuum –unit motor (hp) |
0.5 |
| Boiler heater ( kw) |
8 |
| Pump motor(hp) |
0.75 |
| Compressor motor (hp) |
2 |
| Over all Dimensions including boiler & compressor (mm) |
1620x1070x1500 |
| Net Weight (kg) |
362 |
|
|
|
 |
|
|
|
|
|
 |
